Here's a Docker Compose configuration for n8n, the workflow automation tool, including basic setup with PostgreSQL for persistence:
```yaml
version: '3'
services:
n8n:
image: n8nio/n8n
container_name: n8n
restart: unless-stopped
ports:
- "5678:5678"
environment:
- N8N_BASIC_AUTH_ACTIVE=true
- N8N_BASIC_AUTH_USER=<your-username>
- N8N_BASIC_AUTH_PASSWORD=<your-password>
- DB_TYPE=postgresdb
- DB_POSTGRESDB_DATABASE=n8n
- DB_POSTGRESDB_HOST=postgres
- DB_POSTGRESDB_PORT=5432
- DB_POSTGRESDB_USER=n8n
- DB_POSTGRESDB_PASSWORD=n8n
- N8N_HOST=${HOSTNAME}
volumes:
- n8n_data:/home/node/.n8n
depends_on:
- postgres
networks:
- n8n_network
postgres:
image: postgres:14
container_name: postgres
restart: unless-stopped
environment:
- POSTGRES_DB=n8n
- POSTGRES_USER=n8n
- POSTGRES_PASSWORD=n8n
volumes:
- postgres_data:/var/lib/postgresql/data
networks:
- n8n_network
volumes:
n8n_data:
postgres_data:
networks:
n8n_network:
driver: bridge
```
---
Key Configuration Notes
1. Authentication:
- Update `<your-username>` and `<your-password>` for basic auth
- Remove `N8N_BASIC_AUTH_*` env vars if you want open access (not recommended)
2. Database:
- PostgreSQL is configured for data persistence
- Change database credentials in both n8n and postgres services
3. Ports
- Web UI accessible at `http://localhost:5678`
- Adjust host port (`5678`) if needed
4. Volumes
- Persistent storage for workflows and PostgreSQL data
- Data survives container restarts/updates
How to Use
1. Save as `docker-compose.yml`
2. Run:
```bash
docker-compose up -d
```
3. Access the UI at `http://localhost:5678`
---
Common Customizations
Add Email/SMTP:
```yaml
environment:
- N8N_EMAIL_MODE=internal
- N8N_SMTP_HOST=smtp.example.com
- N8N_SMTP_PORT=587
- N8N_SMTP_USER=user@example.com
- N8N_SMTP_PASSWORD=your-password
```
Enable Webhook URLs
```yaml
environment:
- WEBHOOK_URL=https://your-domain.com
```
Scale Workers
```yaml
environment:
- N8N_EXECUTIONS_MODE=queue
- N8N_QUEUE_BULL_REDIS_HOST=redis
- N8N_QUEUE_BULL_REDIS_DB=0
```
Troubleshooting
1. Check logs
```bash
docker-compose logs -f n8n
```
2. Verify database connection
```bash
docker exec -it postgres psql -U n8n -d n8n
```
3. Reset credentials
```bash
docker-compose down -v && docker-compose up -d
```
For production deployments, consider adding:
- Reverse proxy (Nginx/Caddy)
- SSL certificates
- Redis for queue management
- Backup strategy for volumes
